PhaseCap HD
Product Details
The PhaseCap HD series is a follow-on development of the MKK AC series, covering the power range above 40 through 60 kvar with just one capacitor in a cylindrical aluminum case. The PhaseCap HD is especially intended for industrial applications with demands for long life, constant capacitance and high inrush current withstand capability up to 300 · IR. Such applications require typical power steps of 25 or 50 kvar switched by a PFC controller via each capacitor contactor. This MKK AC series was developed to increase packing density per bank and cut component costs.
Applications
- Automatic PFC equipment, capacitor banks
- Individual fixed PFC (e.g. motors, transformers, lighting)
- Group fixed PFC
- Tuned and detuned capacitor banks
- Filter applications
- Dynamic PFC
- PFC systems with space constraints
3-Phase Capacitors
|
50 Hz Output kvar |
d x h mm |
Weight kg |
Type | Ordering code |
|---|---|---|---|---|
| Rated voltage 400 V AC | ||||
| 40.0 | 136x317 | 4,4 | MKK400-D-40.0-21 | B25669A3796J375 |
| 50.0 | 136x355 | 4,7 | MKK400-D-50.0-21 | B25669A3996J375 |
| Rated voltage 440 V AC | ||||
| 4 0.0 | 136x317 | 4,4 | MKK440-D-40.0-21 | B25669A4657J375 |
| 50.0 | 136x355 | 4,7 | MKK440-D-50.0-21 | B25669A4827J375 |
| 56.0 | 136x355 | 4,7 | MKK440-D-56.0-21 | B25669B4927J375 |
| Rated voltage 525 V AC | ||||
| 40.0 | 136x355 | 4,7 | MKK525-D-40.0-21 | B25669A5467J375 |
